The Reverse Engineering Laboratory supports local and national industry to create 3D models from physical parts and products. Within one lab, we can reverse engineer a part, make design modifications and inspect to the new design or original CAD data.

Capabilities

  • High Detailed 3-D Laser Scanning and point cloud generation
  • Long Range 3-D Laser Scanning and point cloud generation
  • Digital Inspection of physical parts
  • Reverse Engineering physical parts to solid
  • CAD geometry

Reverse Engineering Lab Equipment

  • Hexagon Metrology 4.5.4 SF CMM
    - Shop Floor CMM
  • 6' Romer Absolute Arm
    - Point repeatability less than .025mm
  • CMS 108 Scan Head to attach to Romer Arm
    - Captures 30,000 points per second
    - Point Cloud Accuracy: 0.002"
  • Leica P40 HDR 3D Scanner
    - Hemispherical scanning up to 885ft
    - Up to 1 million points per second
    - HDR imaging integrated into scan data
  • Leica Absolute Tracker AT901 & Leica Absolute Tracker AT960
    - Portable Long range CMM and Target Tracking
    - T-Scan, T-Probe, T-Mac
    - Long Range Scanning and Probing
  • Surphaser25HSX Hemispherical Scanner
    - Portable long range scanning
    - 1.2 million points per second scanning
    - Range: Approximately 200ft
  • Cognitens WLS400A White Light System
    - Field of View: 20"x20" or 27.5"x27.5"
    - Point Cloud Accuracy: 0.004"
  • Q-Flash White Light System
    - Field of View: 14"x14"
    - Point Cloud Accuracy: 0.004"
    - Portable and handheld
  • Creaform Go!SCAN 50
    - Handheld portability
    - Instant data alignment from parts geometry
    - Full Color Scan
    - Part Size range 1 - 10ft

Software Available

  • CATIA V5 & V6
  • Spacial Analyzer
  • Polyworks
  • Magics
